Introduction

Blast furnace slag dryer is defined as a device in which solids are dried while being transported along the interior of a rotating cylinder equipped with lifting flights to shower the solids through the hot gas. Through heat exchange, it is to r educe or minimize moisture content of the material it is drying. By bagasse drying machine, people could get the finished product which is suitable for packing, transportation, subsequent process, etc.

Flowchart Of Slag Dryers:

Features

1.largely increase heat transfer rate and vaporization rate;

2.vaporization capacity per hour is as much as 25-60 kg/m2, which is 1-2 times of traditional rotary dryer;

3.output is raised by 50% and fuel consumption is reduced by 30%;

4.drying efficiency is raised by 40%;

5.save 40% space and civil investment and 20%equipment investment.

Parameter

MODEL	CAPACITY (t/h)	SLOPE (%)	GEARBOX	MOTOR	POWER (kW)
Ø1.0×10m	1-2	5	ZQ400	YCT200-4B	7.5
Ø1.2×12m	2-3	5	ZQ500	YCT225-4A	11
Ø1.5×15m	3-5	5	ZQ500	YCT225-4B	15
Ø1.8×18m	4-6	4	ZQ750	YCT250-4B	22
Ø2.0×20m	7-9	3.5	ZQ750	YCT280-4A	30
Ø2.2×22m	8-10	3.5	ZQ850	YCT315-4A	37
Ø2.4×24m	12-15	3.5	ZQ850	YCT315-4B	45
Ø2.8×28m	16-22	3.5	ZS145	YCT355-4A	55
Ø3.0×30m	20-25	3.5	ZS165	YCT355-4B	75
Ø3.2×32m	28-32	3.5	ZL130	YCT355-4C	90
Ø3.6×36m	38-40	3.5	ZL130	YVF2-315L2-6	132
