Stone Crushing Plant

Max Feeding Size: 340 - 630 (mm)

Output Size: 1 - 50 (mm)

Applicable materials: Stone, aggregate, gravel, granite, construction waste, etc.

Main Equipment: CrusherVibrating ScreenVibrating Feeder, Conveyor

Whatsapp: +86 18037866379
Send e-mail: mic@zkcorp.com
Get a Quote
Chat Online

Introduction

We provide one-stop service of Stone crushing plant, included design, manufacture and installation, which can be used for rock ore materials crushing, building materials crushing and other similar operations. Crushing plant equipments are fixed, which is widely used in many sectors of mining, smelting, building material, highway, railway, water conservancy and chemical industry.

ZK Corp Stone Crushing plant includes :
1. vibrating feeder             2.  jaw crusher           3. impact crusher              4.  cone crusher
5. vibrating screen            6.  belt conveyor
       7. centrally electric controlling system, etc.

We provide a whole set of equipent for stone crushing plant, which can crush many kinds of materials, for example, high hard, mid hard and soft rocks and ores such as iron ore, limestone, slag, marble, quartz, granite, cement, clinker and so on.

Features

1. Good gravel particle shape, reasonable grade and less grinding power.

2. Equipment investment is 25-50% less than conventional production line, short investment recovery period and significant economic benefit.

3. Automation, high degree of information technology, high production efficiency and less employee.

Parameter

Maximum Feeding Size
(mm)
Capacity
(t/h)
Vibrating Feeder
Jaw Crusher
Fine Crushing Equipment
(Impact Crusher)
Vibrating Screen
Installed Power
(KW)
340
30
GZD2511(3kw)
PE400×600(30kw)
PF1007(45kw)
3YZ1236(15kw)
120
340
50
GZD3117(10kw)
PE400×600(30kw)
PF1007(45kw)
3YZ1545(22kw)
140
420
80
GZD3617(10kw)
PE500×750(55kw)
PF1010(75kw)
3YZ1548(22kw)
200
480
100
GZD4321(13kw)
PE600×900(75kw)
PF1210(130kw)
3YZ1548(22kw)
280
560
150
GZD4321(13kw)
PE750×1060(90kw)
PF1210(130kw)
3YZ1845(22kw)
300
630
200
GZD4321(13kw)
PE900×1060(110kw)
PFB1212(140kw)
3YZ2050(30kw)
350
