Type: High Weir, Submerged
Model: FG, 2FG, FC, 2FC
Spiral dia: Φ500 - Φ3000 (mm)
Application: Ore Beneficiation Plants
Model |
Spiral dia. |
Spiral speed |
Output |
Motor power |
||
Circulating load (t/24h) |
Overflow quantity (t/24h) |
Lift/lower (kw) |
Drive (kw) |
|||
High-wear single spiral classifier |
||||||
FG-5 |
Φ500 |
8.5-15.5 |
143-261 |
32 |
|
1.1 |
FG-7 |
Φ750 |
4.5-9.9 |
256-564 |
65 |
|
3 |
FG-10 |
Φ1000 |
3.5-7.6 |
473-1026 |
85 |
|
5.5 |
FG-12 |
Φ1200 |
5,6,7 |
1170-1600 |
155 |
2.2 |
5.5 |
FG-15 |
Φ1500 |
2.5,4,6 |
1140-2740 |
235 |
2.2 |
7.5 |
FG-20 |
Φ200 |
3.6,5.5 |
3890-5940 |
400 |
3 |
11,15 |
FG-24 |
Φ2400 |
3.64 |
6800 |
580 |
3 |
15 |
FG-30 |
Φ3000 |
3.2 |
11650 |
893 |
4 |
22 |
High-wear double spiral classifier |
||||||
2FG-12 |
Φ1200 |
5,6,7 |
2340-3200 |
310 |
2.2x2 |
5.5x2 |
2FG-15 |
Φ1500 |
2.5,4,6 |
2280-5480 |
470 |
2.2x2 |
7.5x2 |
2FG-20 |
Φ2000 |
3.6,5.45 |
7780-11880 |
800 |
3x2 |
22,30 |
2FG-24 |
Φ2400 |
3.67 |
13600 |
1160 |
3x2 |
30 |
2FG-30 |
Φ3000 |
3.2 |
23300 |
1785 |
4x2 |
40 |
Submerged single spiral classifier |
||||||
FC-12 |
Φ1200 |
2.5,4,6 |
1170-1630 |
120 |
2.2 |
7.5 |
FC-15 |
Φ1500 |
2.5,4,6 |
1140-2740 |
185 |
2.2 |
7.5 |
FC-20 |
Φ2000 |
3.6,5.5 |
3890-5940 |
320 |
3 |
11,15 |
FC-24 |
Φ2400 |
3.64 |
6800 |
455 |
4 |
18.5 |
FC-30 |
Φ3000 |
3.2 |
11650 |
705 |
4 |
22 |
Submerged double spiral classifier |
||||||
2FC-12 |
Φ1200 |
3.8,6 |
1770-2800 |
240 |
2.2x2 |
7.5x2 |
2FC-15 |
Φ1500 |
2.5,4,6 |
2280-5480 |
370 |
2.2x2 |
7.5x2 |
2FC-20 |
Φ2000 |
3.6,5.5 |
7780-11880 |
640 |
3x2 |
22,30 |
2FC-24 |
Φ2400 |
3.67 |
13700 |
910 |
3x2 |
30 |
2FC-24 |
Φ2400 |
3.67 |
13700 |
910 |
4x2 |
37 |
2FC-30 |
Φ3000 |
3.2 |
23300 |
1410 |
4x2 |
45 |
