TH Bucket Elevator

Model: TH160 - TH500



Capacity: 3.1 - 70 (m³/h)



Bucket movement speed: 1.0 - 1.37 (m/s)



Bucket Type: Deep / Light Bucket

Whatsapp: +86 18037866379
Send e-mail: mic@zkcorp.com
Get a Quote
Chat Online

Introduction

TH Bucket Elevator is a kind of continuous vertical lifting equipment with chain type bucket to process bulk material. It is mainly used for lifting bulk material and crushed material with the property of low hardness. It is widely used in power, chemistry, metallurgy, building material, light industry, grain, mining and etc. The lifted material with the temperature under 250℃. It has the features of high capacity, reliable working, small area needed, high lifting height and easy maintenance. In the driving system, it has the high reliable non-return structure to prevent temporary power off or other fault causing shut off under the loading condition to make drive and lifting hopper return moving to cause fault.

TH Bucket Elevator is used for lifting powder, granular materials and small block and grinding of small materials vertically, such as: coal, cement, stones, sand, clay, ore and so on. or other industries of dry mortar for construction, chemistry and foodstuff.


Features

1. Compact Machine Structure, small overall dimension, small space needed.

2. Adopt the taking out type material loading and mixing type material discharging. The hopper volume is big with high density layout. It has the feature of big lifting scope, high lifting height and high transportation capacity.

3. Each section and maintenance door have the sealing device to make sure no dust outlet to realize clean and friendly environment production.

4. Drive sprocket wheel is a overall structure, the surface has been specially strengthen processed. It has the features of easy operation, high strength and wearing resistance.

5. Adopt low alloy high strength round ring chain as driving part. Under the special technology process, it has the features of anti-pulling strength, good wearing resistance, long time using, good hopper connection, and easy to be maintenance.

Parameter

Model

TH160

TH250

TH315

TH400

TH500

Capacity (m³/h)

Deep Bucket

Light Bucket

Deep Bucket

Light Bucket

Deep Bucket

Light Bucket

Deep Bucket

Light Bucket

Deep

 Bucket

8

3.1

14

6.8

28

16

47.2

30

70

Hopper

Bucket Type

Deep Bucket

Light Bucket

Deep Bucket

Light Bucket

Deep Bucket

Light Bucket

Deep Bucket

Light Bucket

Deep Bucket

Volume L

1.1

0.65

3.2

2.6

5.2

4.4

10.5

10

15

Bucket Distance mm

400

400

400

400

500

500

500

500

600

Ring Chain

Pitch Qty

7

7

9

9

7

(mm)

φ14×50

φ14×50

φ18×50

φ18×50

φ22×75

Chain Hook

(mm)

φ14×M12

φ14×M12

φ18×M14

φ18×M14

φ25×M20

Bucket movement speed (m/s)

1.0

1.25

1.25

1.25

1.37

Drive Shaft Speed ( rpm)

47.5

47.5

37.5

37.5

36.5
