Waste Rotary Incinerator

Model: Φ1.6x32m - Φ4.7x72m



Capacity: 2.0 - 34 (t/h)



Application: Waste processing



Applied Material: Hazardous waste, sludge waste, oil sludge, industrial waste, etc.

Whatsapp: +86 18037866379
Send e-mail: mic@zkcorp.com
Get a Quote
Chat Online

Introduction

Rotary incinerator is a widely used incineration equipment in the field of international industrial waste treatment, its market share in the field of industrial waste incineration is really high. As a specific area for burning hazardous wastes, the rotary incinerator has wide adaptability to complex industrial waste and living waste, and it’s stable and convenient to operate, the equipment maintenance is simple, and so on. Therefore, it is the most widely used in the field of international hazardous waste incineration. It is a reliable and effective means to realize the harmless, reduction and recycling of wastes.

Applicable material of rotary incinerator:
It is widely used in the field of industrial waste, hazardous waste, sludge waste, oily sludge, industrial waste, PVC material, municipal waste, and so on.

Features

1. Low cost: High temperature material contact refractory material. Replacing lining is convenient;

2. The driving mechanism is simple: The drive mechanism is in the kiln housing. the equipment maintenance is easy.;

3. Ensure that harmful gases do not leak: Good sealing measures and furnace negative pressure.

4. Easy to operate and maintain: Equipment running rate is high. The annual operation rate is generally 90%.

5. Adaptability to incineration: Solid waste ,liquid, colloid, and gas can be incinerated simultaneously.

6. High heat utilization rate: The material was churned forward. The three heat transfer modes coexist in one furnace.

7. Combining patented technology: The traditional two combustion chamber is evolved into a two combustion furnace. The burnout rate of ash is improved. The combustion efficiency of rotary kiln is improved. At the same time, it has the functions of slag discharging at normal temperature, crushing slag and sealing, locking air, etc.

Parameter

Hazardous waste rotary kiln for waste incineration φ2.6m*13.2 technical parameter.

Inner diameter of shell 2600mm

Shell length 13200mm

Downstream arrangement, that is, the direction of material flow is consistent with the direction of smoke flow, the angle of the kiln body is 1.5 degrees.

Variable frequency speed control of rotary kiln

0.1-2.2r/min

Drive mode

Single side gear drive

Main Motor

30kw

Kiln temperature:850-1200 degree

Surface temperature of kiln shell: 180 degree

Expansion mode

Linear free expansion at both ends

Total equipment weight

 approx. 54.5t

★Customized waste incineration rotary kiln can be provided according to the customers' different industries
