Introduction
ZK Corp offers a wide range of mobile belt conveyor , which is used as effective bulk material handling equipment. It effectively used for handling variety of bulk materials. Our range of mobile belt conveyor systems come with arrangement to convey bulk materials as well as to weight sort (magnetically).
Mobile belt conveyor can be horizontal, tilt and vertical transmission, but also the composition of space transmission lines, transmission lines are generally fixed. mobile conveyor belt transport capacity, long-distance, but also in the transportation process while completing a number of process operation, it is widely used. Main belt conveyor:plate conveyor, scraper conveyor, screw conveyor,bucket conveyor, bucket elevator, overhead conveyors and so on. mobile conveyor belt for conveying bulk density of less than 1.67 / t / cubic meter, easy to dig a powder, granular, small block of low-abrasive materials and bags of materials, such as coal, gravel, sand, cement, fertilizer, and grain. Sent material temperature is less than 60 °C. The form of their captain and assembly can be determined according to user requirements, transmission can be electric drum can also be used with a drive rack drive.
Features
1.Light weight, one operator can move it easily.
2.Lifting height can be adjust according to your need.
3.Belt conveyor system provides gentle handling and higher capacity than the same size screw conveyor.
4.With wheels and can be moved to anywhere to save equipment number.
5.Easier for bags or bulk material stacking in warehouse to save your labor cost.
6.Adopt chevron pattern conveyor belt to increase the maximum conveyor angle.
7.The conveyor length can be customized according to your requirement.
Parameter
|
Width (mm) |
Length (m) / Power (kw) |
Speed (m/s) |
Capacity (t/h) |
|
400 |
≤12/2.2 |
12~20 /2.2~4 |
20~25/3.5~7.5 |
1.25~2.0 |
30~60 |
|
500 |
≤12/3 |
12~20/3~5.5 |
20~30/5.5~7.5 |
1.25~2.0 |
40~80 |
|
650 |
≤12/4 |
12~20/4~5.5 |
20~30/5.5~11 |
1.25~2.0 |
80~120 |
|
800 |
≤10/4 |
10~15/4~5.5 |
15~30/5.5~15 |
1.25~2.0 |
120~200 |
|
1000 |
≤10/5.5 |
10~20/5.5~11 |
20~40/11~22 |
1.25~2.0 |
200~320 |
|
1200 |
≤10/7.5 |
10~20/7.5~15 |
20~40/15~30 |
1.25~2.0 |
290~480 |
