Introduction

In order to satisfy the domestic petroleum requirement, the petroleum exploitation industry develops rapidly, the related product also expanding rapidly. Hence, it promotes Chinese oil fracturing proppant industry continues development, and rotary kiln is the critical equipment for the oil fracturing proppant calcination.

ZK rotary kiln is constantly optimize after discuss with many senior experts and refer experiences for many years. At present, ZK designed a series of oil fracturing proppant rotary kiln according to the industry demand.

Features

1. Oil fracturing proppant rotary kiln adopts adjustable speed driving with high efficient and low power consumption.

2. The fuel consumption of unit product is low and large capacity.

3. The layout of system equipment is compact and simple structure, the maintenance is convenient with light weight and low investment for civil construction.

4. Simple structure, high unit volume, long furnace life, high operation rate, stable operation, high heat transfer efficiency, low heat consumption;

5. Temperature automatic control, over-temperature alarm, the second use of waste heat into the wind, kiln lining long life;

6. Advanced kiln head and tail sealing technology and devices, stable operation, high output and other significant features.

Parameter

Model	Capacity (t/h)	Support	Reducer	Motor	Power (kW)
Φ2.2×45m	3.5	3	ZS125-5	YVF2-225M-4	45
Φ2.5×50m	5	3	ZS145-5	YVF2-250M-4	55
Φ2.8×50m	8.5	3	ZS165-6	YVF2-280S-4	75
Φ3.0×55m	11	3	ZS165-3	YVF2-280M-4	90
Φ3.2×60m	15	3	ZL130-16	YVF2-315L2-6	132
Φ3.6×64m	20	3	ZSY560-63	YVF2-355M1-6	160
Φ3.8×70m	26	3	ZSY560-63	YVF2-355M4-6	200
