NE Bucket Elevator

NE Bucket Elevator

Model: NE15 - NE400



Capacity: 10 - 450 (m³/h)



Max. feeding size: 40 - 130 (mm)



Max. height: ≤ 45 (m)

Whatsapp: +86 15237956296
Send e-mail: mic@zkcorp.com
Leave a Message
Chat Online

Introduction

NE series bucket elevator is a chain type vertical conveyor be common used in many industries. It main be used transport powder, particle and block materials, and also for large abrasion material, such as cement, sand, coal, limestone, proppant sand, etc. Widely used in construction, power, metallurgy, machinery, chemical, mining industry and so on.

NE bucket elevator adopt flow-through loading, reducing the bucket wearing from material efficiency. Improve the performance of bucket elevator. The temperature of material is below 200℃ usually, and the conveying height can be reach to 45 meters.

Features

1. Large scope of elevate: not only elevate common powder, particle and block materials, but also can elevate large abrasion materials;

2. Small power for driving, low energy consumption, save energy effective; compare with roller chain bucket elevator, if elevate same material to same height, energy consume is around 1/3-1/2;

3. Adoption complete sealing design, there is no dust pollution during operation;

4. Shell with indent structure , strong rigidity, high precise, nice appearance.

Parameter

Model Elevation
Capacity
(m³/h)
Maximum
Granularity
(mm)
Material
Loose Density
(t/m³)
Maximum
Lifting Height
(m)
Power
(Kw)
Bucket
Movement Speed
(m/s)
NE15 10-15 40 0.6-2.0 35 1.5-4.0 0.5
NE30 18.5-31 55 0.6-2.0 50 1.5-11 0.5
NE50 35-60 60 0.6-2.0 45 1.5-18.5 0.5
NE100 75-110 70 0.6-2.0 45 5.5-30 0.5
NE150 112-165 90 0.6-2.0 45 5.5-45 0.5
NE200 170-220 100 0.6-1.8 40 7.5-55 0.5
NE300 230-340 125 0.6-1.8 40 11-75 0.5
NE400 340-450 130 0.8-1.8 30 18.5-90 0.5
